LTM190E1-L03

LTM190E1-L03
LTM190E1-L03
LTM190E1-L03 thumb LTM190E1-L03 thumb
Merek
Samsung
Ukuran
19.0
Aplikasi
DMPC
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
250
CR
600:1
Warna
16.7M
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
704
Spesifikasi

Nomor Bagian LTM190E1-L03
MerekSamsung
Ukuran19.0
AplikasiDMPC
Resolusi1280×1024
KomposisiLCM
Kecerahan250
CR600:1
Warna16.7M
Lampu latarCCFL
AntarmukaLVDS
merek panelSAMSUNG
model panelLTM190E1-L03
tipe panel a-Si TFT-LCD , LCM
ukuran panel19.0 inch
resolusi1280(RGB)×1024 , SXGA
mode tampilanPVA, Normally Black, Transmissive
daerah aktif376.32×301.056 mm
garis besar402.4×330×20.3 mm
permukaanAntiglare (Haze 44%), Hard coating (3H)
kecerahan250 cd/m² (Typ.)
rasio kontras600:1 (Typ.)
menampilkan warna16.7M (8-bit)
waktu merespon15/10 (Typ.)(Tr/Td)
sudut pandang85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu4 pcsCCFLWithout Driver
antarmuka sinyalLVDS (2 ch, 8-bit), 30 pins
tegangan masukan5.0V (Typ.)
aplikasiDMPC
