Nomor Bagian | LTM14C421F |
Merek | TOSHIBA |
Ukuran | 14.1 |
Aplikasi | NBPC |
Resolusi | 1024×768 |
Komposisi | LCM |
Kecerahan | |
CR | |
Warna | 262K |
Lampu latar | CCFL |
Antarmuka | LVDS |
merek panel | TOSHIBA |
model panel | LTM14C421F |
tipe panel | a-Si TFT-LCD , LCM |
ukuran panel | 14.1 inch |
resolusi | 1024(RGB)×768 , XGA |
mode tampilan | Transmissive |
daerah aktif | 285.696×214.272 mm |
gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
permukaan | |
kecerahan | |
rasio kontras | |
menampilkan warna | 262K (6-bit) |
waktu merespon | |
sudut pandang | |
frekuensi | 60Hz |
jenis lampu | 1 pcsCCFL |
antarmuka sinyal | LVDS (1 ch, 6-bit) |
aplikasi | NBPC |
B141EW02 V3 | AUO | 14.1 | 1280×800 |
B141PW03 V0 | AUO | 14.1 | 1440×900 |
B141XG09 V0 | AUO | 14.1 | 1024×768 |
B141XN01 V0 | AUO | 14.1 | 1024×768 |
LP141WX1-TLE3 | LG Display | 14.1 | 1280×800 |
LP141X2 | LG Display | 14.1 | 1024×768 |
LT141DEQ8B00 | TOSHIBA | 14.1 | 1440×900 |
LTM14C421F | TOSHIBA | 14.1 | 1024×768 |
LTN141AT09-201 | Samsung | 14.1 | 1280×800 |
LTN141BT08-002 | Samsung | 14.1 | 1440×900 |
B141EW03 V3 | AUO | 14.1 | 1280×800 |
B141PW03 V1 | AUO | 14.1 | 1440×900 |
LP140WH1-TLA2 | LG Display | 14.0 | 1366×768 |
LP141WX1-TL02 | LG Display | 14.1 | 1280×800 |
LP141WX1-TL04 | LG Display | 14.1 | 1280×800 |
LTN133AT25-501 | Samsung | 13.3 | 1366×768 |
LTN150U2-L02 | Samsung | 15.0 | 1600×1200 |
N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
N133FGE-L31 | Innolux | 13.3 | 1600×900 |
N134B6-L01 | Innolux | 13.4 | 1366×768 |
