| Nomor Bagian | LTM12C505D |
| Merek | TOSHIBA |
| Ukuran | 12.1 |
| Aplikasi | NBPC |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 165 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | Toshiba Matsushita |
| model panel | LTM12C505D |
| tipe panel | LTPS TFT-LCD , LCM |
| ukuran panel | 12.1 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 245.76×184.32 mm |
| garis besar | 261×199×5.3 mm |
| permukaan | |
| kecerahan | 165 cd/m² (Typ.) |
| rasio kontras | 350:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 50/50 (Max.)(Tr/Td) |
| sudut pandang | |
| frekuensi | 60Hz |
| jenis lampu | 1 pcsCCFLEmbedded (Inverter) |
| antarmuka sinyal | LVDS (1 ch, 6-bit), 20 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | NBPC |
