Samsung LTA320HN02-W lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


LTA320HN02-W

LTA320HN02-W
LTA320HN02-W
LTA320HN02-W
LTA320HN02-W thumb LTA320HN02-W thumb LTA320HN02-W thumb
Merek
Samsung
Ukuran
31.5
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
430
CR
5000:1
Warna
1.07B
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
3845
Spesifikasi

Nomor Bagian LTA320HN02-W
MerekSamsung
Ukuran31.5
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan430
CR5000:1
Warna1.07B
Lampu latarCCFL
AntarmukaLVDS
merek panelSAMSUNG
model panelLTA320HN02-W
tipe panel a-Si TFT-LCD , LCM
ukuran panel31.5 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanSVA, Normally Black, Transmissive
daerah aktif698.4×392.85 mm
garis besar760×450 mm
permukaanAntiglare (Haze 5.5%), Hard coating (2H)
kecerahan430 cd/m² (Typ.)
rasio kontras5000:1 (Typ.)
menampilkan warna1.07B (8-bit + Hi-FRC), CIE193172%
waktu merespon12/8 (Typ.)(Tr/Td); 8 (Typ.)(MPRT)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu4 pcsCCFLEmbedded (Inverter)
antarmuka sinyalLVDS (2 ch, 10-bit), 51 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
LTA320AN01-C Samsung 31.5 1366×768
LTA320AP05 Samsung 31.5 1366×768
LTA320AP16 Samsung 31.5 1366×768
LTA320AP18 Samsung 31.5 1366×768
LTA320AP21 Samsung 31.5 1366×768
LTA320HJ03 Samsung 31.5 1920×1080
LTA320HN03-W Samsung 31.5 1920×1080
LTA320W1-L02 Samsung 31.5 1280×768
LTA320W2-L03 Samsung 31.5 1366×768
LTA320WT-LF1 Samsung 31.5 1366×768
