| Nomor Bagian | LSI490HN01-V |
| Merek | SAMSUNG |
| Ukuran | 49 |
| Aplikasi | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 4000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | SAMSUNG |
| model | LSI490HN01-V |
| ukuran diagonal | 49 inch |
| jenis | a-Si TFT-LCD, CELL |
| format piksel | 1920(RGB)×1080 [FHD] 45PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 1073.78(H)×604(V) mm |
| garis besar redup. | 1083.78(H)×615.5(V) ×1.3(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 25%), Hard coating (2H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 4000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 6 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | SPVA, Normally Black, Transmissive |
| ketebalan pelat | 0.40+0.50 mm |
| transmisi | 6.79% (Typ.)(with Polarizer) |
| warna pendukung | 1.07B 99% sRGB |
| sumber cahaya | No B/L |
| berat | 1.80±0.18Kgs |
| dirancang untuk | Digital Signage |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| detail d-ic | COF Built-in 6 source chips |
| tipe antarmuka | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
