| Nomor Bagian | LSC490HN05-W |
| Merek | SAMSUNG |
| Ukuran | 49 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 6000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | LVDS |
| merek | SAMSUNG |
| ukuran diagonal | 49 inch |
| format piksel | 1920×1080(RGB) [FHD] 45PPI |
| daerah aktif | 1073.78(H)×604(V) mm |
| daerah bezel | - |
| pencahayaan | 0 cd/m² |
| arah pandangan | Symmetry |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| ketebalan pelat | - |
| warna pendukung | 16.7M 99% NTSC |
| berat | 1.70Kgs (Typ.) |
| kecepatan bingkai | 60Hz |
| detail d-ic | COF Built-in 2 source chips |
| tipe antarmuka | LVDS (2 ch, 10-bit) , 51 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
| model | LSC490HN05-W |
| jenis | a-Si TFT-LCD , CELL |
| konfigurasi | RGB Horizontal Stripe |
| garis besar redup. | 1078.78(H)×617.8(V) ×1.3(D) mm |
| perlakuan | Antiglare (Haze 2.3%), Hard coating (2H) |
| rasio kontras | 6000:1 (Typ.) (TM) |
| waktu merespon | 8 (Typ.)(G to G) |
| Modus operasi | SVA, Normally Black, Transmissive |
| transmisi | 6.9% (Typ.)(with Polarizer) |
| sumber cahaya | No B/L |
| dirancang untuk | TV Sets |
| panel sentuh | Without |
