| Nomor Bagian | LSC480HN08-W |
| Merek | SAMSUNG |
| Ukuran | 48 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | CELL, a-Si TFT-LCD |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | LVDS |
| pabrikan | SAMSUNG |
| nama model | LSC480HN08-W |
| ukuran layar | 48 inch |
| tipe layar | CELL, a-Si TFT-LCD |
| nomor piksel | 1920×1080(RGB) (FHD) 46PPI |
| pengaturan | RGB Horizontal Stripe |
| area aktif (mm) | 1054.08 × 592.92 (H×V) |
| garis besar (mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antiglare (Haze 2.3%), Hard coating (2H) |
| pencahayaan | 0 cd/m² |
| rasio kontras | 5000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 8 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | SVA, Normally Black, Transmissive |
| ketebalan kaca | 0.50+0.50 mm |
| keterusan | 6.6% (Typ.)(with Polarizer) |
| kedalaman warna | 1.07B 68% NTSC |
| lampu latar | No B/L |
| massa | 1.90Kgs (Typ.) |
| digunakan untuk | TV Sets |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| daftar ic driver | Built-in COF 3 source chips |
| jenis sinyal | LVDS (2 ch, 10-bit) , Connector 51 pins |
| sumber tegangan | 12.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
