| Nomor Bagian | LS055R3SX01 |
| Merek | Sharp |
| Ukuran | 5.5 |
| Aplikasi | Mobile Phone |
| Resolusi | 1536×2560 |
| Komposisi | CG-Silicon , LCM |
| Kecerahan | |
| CR | 1280:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | Sharp |
| ukuran diagonal | 5.5 inch |
| format piksel | 1536(RGB)×2560 546PPI |
| daerah aktif | 71.424(H)×119.04(V) mm |
| pencahayaan | 460 cd/m² (Typ.) |
| arah pandangan | Symmetry |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| warna pendukung | 16.7M 70% NTSC |
| berat | 21.1g |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | MIPI (4 data lanes) , 32 pins Connector |
| Sumber Daya listrik | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| lingkungan | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | LS055R3SX01 |
| jenis | CG-Silicon , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 73.824(H)×126.44(V) ×1.4(D) mm |
| rasio kontras | 1280:1 (Typ.) (TM) |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| Modus operasi | New Mode2, Normally Black, Transmissive |
| sumber cahaya | WLED [8S2P] , W/O Driver |
| dirancang untuk | Mobile Phone |
| panel sentuh | Without |
