| Nomor Bagian | LQ6NC02 |
| Merek | SHARP |
| Ukuran | 5.7 |
| Aplikasi | |
| Resolusi | 240×240 |
| Komposisi | LCM |
| Kecerahan | 120 |
| CR | |
| Warna | Full color |
| Lampu latar | CCFL |
| Antarmuka | Analog |
| merek panel | SHARP |
| model panel | LQ6NC02 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 5.7 inch |
| resolusi | 240(RGB)×240 |
| mode tampilan | TN, Normally White, Transmissive |
| daerah aktif | 113.8×87.6 mm |
| garis besar | 149.4×117 mm |
| permukaan | |
| kecerahan | 120 cd/m² (Typ.) |
| rasio kontras | |
| menampilkan warna | Full color |
| waktu merespon | 30/50 (Typ.)(Tr/Td) |
| sudut pandang | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antarmuka sinyal | Analog RGB + Composite Video (NTSC), 20 pins |
| tegangan masukan | 5.0V (Typ.) |
