| Nomor Bagian | LQ173D1JW32 |
| Merek | Sharp |
| Ukuran | 17.3 |
| Aplikasi | Laptop |
| Resolusi | 3840×2160 |
| Komposisi | Oxide TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | Sharp |
| model panel | LQ173D1JW32 |
| ukuran panel | 17.3" |
| tipe panel | Oxide TFT-LCD, LCM |
| resolusi | 3840(RGB)×2160, UHD, 255PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 382.12(W)×214.94(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 393.69(W)×252(H) ×4(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 300 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 88/88/88/88 (Typ.)(CR≥10) |
| mode tampilan | IPS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 30 (Typ.)(Tr+Td) |
| menampilkan warna | 16.7M 100% Adobe RGB |
| jenis lampu | WLED , 12K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Flat (PCBA Flat, T3.4~4.0mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
