| Nomor Bagian | LQ156Z1JW03B |
| Merek | Sharp |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 3200×1800 |
| Komposisi | LCM , Oxide TFT-LC |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| pabrikan | Sharp |
| ukuran layar | 15.6 inch |
| nomor piksel | 3200(RGB)×1800 (Quad-HD+) 235PPI |
| area aktif (mm) | 345.6 × 194.4 (H×V) |
| area bezel (mm) | - |
| pencahayaan | 300 cd/m² (Typ.) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10) |
| pemandangan bagus di | Symmetry |
| kedalaman warna | 16.7M 100% sRGB |
| bentuk garis besar | Slim (PCBA Flat, T≤3.2mm) |
| tingkat penyegaran | 60Hz |
| jenis sinyal | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | LQ156Z1JW03B (SHP141C) |
| tipe layar | LCM , Oxide TFT-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | 367.98 × 218.21 × 2.85 (H×V×D) |
| perlakuan | Antiglare, Hard coating (3H) |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| tanggapan | 25 (Typ.)(Tr+Td) ms |
| mode kerja | New Mode, Normally Black, Transmissive |
| lampu latar | WLED , With LED Driver |
| digunakan untuk | Laptop |
| layar sentuh | Without |
