| Nomor Bagian | LQ104V1DW02 |
| Merek | SHARP |
| Ukuran | 10.4 |
| Aplikasi | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 380 |
| CR | 450:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antarmuka | TTL |
| merek panel | SHARP |
| model panel | LQ104V1DW02 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 10.4 inch |
| resolusi | 640(RGB)×480 , VGA |
| mode tampilan | ASV, Normally Black, Transmissive |
| daerah aktif | 211.2×158.4 mm |
| garis besar | 246.5×179.4×15.5 mm |
| permukaan | Antiglare, Hard coating (3H), Antireflection |
| kecerahan | 380 cd/m² (Typ.) |
| rasio kontras | 450:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 12/13 (Typ.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 31 pins |
| tegangan masukan | 3.3/5.0V (Typ.)(VCC) |
| aplikasi | IA |
