| Nomor Bagian | LQ050A5AG03 |
| Merek | Sharp |
| Ukuran | 5.0 |
| Aplikasi | Automotive Display |
| Resolusi | 320×234 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 60:1 |
| Warna | Full |
| Lampu latar | 1 |
| Antarmuka | Analog |
| pabrikan | Sharp |
| nama model | LQ050A5AG03 |
| ukuran layar | 5.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 320(RGB)×234 79PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 102.124 × 74.763 (H×V) |
| garis besar (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Antireflection |
| pencahayaan | 320 cd/m² (Typ.) |
| rasio kontras | 60 : 1 (Typ.) (TM) |
| sudut pandang | 65/65/40/65 (Typ.)(CR≥5) |
| tanggapan | 30/50 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | - |
| mode kerja | TN, Normally White, Transmissive |
| kedalaman warna | Full color |
| lampu latar | 1 pcs CCFL , 10K hours , No Driver |
| massa | 180g (Max.) |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | - |
| layar sentuh | Without |
| jenis sinyal | Analog RGB , Connector 22 pins |
| sumber tegangan | 8.0/-5.0V (Typ.)(VSH/VSL) |
| maks. peringkat | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
