| Nomor Bagian | LQ038J7DH52 |
| Merek | SHARP |
| Ukuran | 3.8 |
| Aplikasi | MPH |
| Resolusi | 320×480 |
| Komposisi | LCM |
| Kecerahan | 80 |
| CR | 60:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | SHARP |
| model panel | LQ038J7DH52 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.8 inch |
| resolusi | 320(RGB)×480 , HVGA |
| mode tampilan | TN, Normally White, Transflective |
| daerah aktif | 52.8×79.2 mm |
| garis besar | 64.5×92.7 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 80 cd/m² (Typ.) |
| rasio kontras | 60:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 20/35 (Typ.)(Tr/Td) |
| sudut pandang | 55/55/55/55 (Typ.)(CR≥2)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit), 39 pins |
| tegangan masukan | 5.0/3.3/15.0/-10.0V (Typ.)(VSHA/VSHD/VDD/VEE) |
| aplikasi | MPH |
