| Nomor Bagian | LPM089A128A |
| Merek | JDI |
| Ukuran | 8.9 |
| Aplikasi | Pad & Tablet |
| Resolusi | 1536×2048 |
| Komposisi | LTPS TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek | JDI |
| model | LPM089A128A |
| ukuran diagonal | 8.9 inch |
| jenis | LTPS TFT-LCD, LCM |
| format piksel | 1536(RGB)×2048 [QXGA] 288PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 135.245(H)×180.326(V) mm |
| garis besar redup. | 140.85(H)×190.75(V) mm |
| daerah bezel | - |
| perlakuan | Hard coating (3H) |
| pencahayaan | 420 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 30 (Max.)(Tr+Tf) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 71% NTSC |
| sumber cahaya | WLED [7S4P] , W/O Driver |
| berat | 90.26g |
| dirancang untuk | Pad & Tablet |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | MIPI (2 ch, 4 data lanes) , 51 pins Connector |
| Sumber Daya listrik | 1.8/3.8V (Typ.)(IOVDD/AVDD) |
| lingkungan | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| A089SW01 V0 | AUO | 8.9 | 1024×600 |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LTL089CL02-002 | Samsung | 8.9 | 1920×1200 |
| LTM09C362Z | TOSHIBA | 8.9 | 1024×600 |
| N089L6-L03 | Innolux | 8.9 | 1024×600 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
| TFTMD089030 | JDI | 8.9 | 2560×1600 |
