LG Display LP133WX2-TLC1 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


LP133WX2-TLC1

LP133WX2-TLC1
LP133WX2-TLC1
LP133WX2-TLC1
LP133WX2-TLC1 thumb LP133WX2-TLC1 thumb LP133WX2-TLC1 thumb
Merek
LG Display
Ukuran
13.3
Aplikasi
NBPC
Resolusi
1280×800
Komposisi
LCM
Kecerahan
275
CR
600:1
Warna
262K
Lampu latar
WLED
Antarmuka
LVDS
In Stock
500
Spesifikasi

Nomor Bagian LP133WX2-TLC1
MerekLG Display
Ukuran13.3
AplikasiNBPC
Resolusi1280×800
KomposisiLCM
Kecerahan275
CR600:1
Warna262K
Lampu latarWLED
AntarmukaLVDS
merek panelLG.Philips LCD
model panelLP133WX2-TLC1 6 Compatible model
tipe panel a-Si TFT-LCD , LCM
ukuran panel13.3 inch
resolusi1280(RGB)×800 , WXGA
mode tampilanTN, Normally White, Transmissive
daerah aktif286.08×178.8 mm
garis besar307.38×203.1×3.6 mm
gaya bentukFlat (PCBA Flat, Depth 3.4~4.0mm)
permukaanGlare (Haze 0%), Hard coating (2H), Antireflection
kecerahan275 cd/m² (Typ.)
rasio kontras600:1 (Typ.)
menampilkan warna262K (6-bit), CIE193145%
waktu merespon16 (Typ.)(Tr+Td)
sudut pandang45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu9S6PWLEDWithout Driver
antarmuka sinyalLVDS (1 ch, 6-bit), 30 pins
tegangan masukan3.3V (Typ.)
aplikasiNBPC
