| Nomor Bagian | LP125WH2-SPT2 |
| Merek | LG Display |
| Ukuran | 12.5 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| pabrikan | LG Display |
| nama model | LP125WH2-SPT2 |
| ukuran layar | 12.5 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1366(RGB)×768 (WXGA) 125PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 275.59 × 154.94 (H×V) |
| garis besar (mm) | - |
| pencahayaan | 300 cd/m² (Typ.) |
| rasio kontras | 700 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 35 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | AH-IPS, Normally Black, Transmissive |
| kedalaman warna | 262K |
| lampu latar | WLED , 12K hours , With LED Driver |
| bentuk garis besar | - |
| digunakan untuk | Laptop |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | eDP (1 Lane) , Connector |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
