| Nomor Bagian | LP123WQ1-SPA1 |
| Merek | LG Display |
| Ukuran | 12.3 |
| Aplikasi | Laptop |
| Resolusi | 2736×1824 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1400:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | eDP |
| pabrikan | LG Display |
| nama model | LP123WQ1-SPA1 |
| ukuran layar | 12.3 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 2736(RGB)×1824 267PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 259.78 × 173.19 (H×V) |
| garis besar (mm) | 265.38 × 183.49 × 4.25 (H×V×D) |
| area bezel (mm) | 262.18 × 175.59 (H×V) |
| perlakuan | Hard coating (3H) |
| pencahayaan | - |
| rasio kontras | 1400 : 1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| tanggapan | 27/46 (Max.)(Tr/Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | WLED , 12K hours , No Driver |
| bentuk garis besar | Slim (PCBA Bent, T≤3.0mm) |
| digunakan untuk | Laptop |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | eDP (4 Lanes) , HBR2 (5.4G/lane) , Connector 60 pins |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 70 °C Operating Temp.: 0 ~ 60 °C |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
