LG Display LP121X04-C2 lembar data, spesifikasi, stok, aplikasi www.looklcd-id.com
LookLCD LookLCD


LP121X04-C2

LP121X04-C2
LP121X04-C2
LP121X04-C2 thumb LP121X04-C2 thumb
Merek
LG Display
Ukuran
12.1
Aplikasi
NBPC
Resolusi
1024×768
Komposisi
LCM
Kecerahan
143
CR
250:1
Warna
262K
Lampu latar
CCFL
Antarmuka
LVDS
In Stock
18177
Spesifikasi

Nomor Bagian LP121X04-C2
MerekLG Display
Ukuran12.1
AplikasiNBPC
Resolusi1024×768
KomposisiLCM
Kecerahan143
CR250:1
Warna262K
Lampu latarCCFL
AntarmukaLVDS
merek panelLG.Philips LCD
model panelLP121X04-C2 1 Compatible model
tipe panel a-Si TFT-LCD , LCM
ukuran panel12.1 inch
resolusi1024(RGB)×768 , XGA
mode tampilanTN, Normally White, Transmissive
daerah aktif245.76×184.32 mm
garis besar261×199×5.4 mm
permukaanAntiglare (Haze 13%), Hard coating (3H)
kecerahan143 cd/m² (Typ.)
rasio kontras250:1 (Typ.)
menampilkan warna262K (6-bit)
waktu merespon20/30 (Typ.)(Tr/Td)
sudut pandang40/40/15/30 (Min.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu1 pcsCCFLWithout Driver
antarmuka sinyalLVDS (1 ch, 6-bit), 20 pins
tegangan masukan3.3V (Typ.)
aplikasiNBPC
Model Keluarga
LP121S1 LG Display 12.1 800×600
LP121WX3-TLA1 LG Display 12.1 1280×800
LP121WX3-TLB1 LG Display 12.1 1280×800
LP121WX3-TLC1 LG Display 12.1 1280×800
LP121WX3-TPB1 LG Display 12.1 1280×800
LP121WX4-TLA1 LG Display 12.1 1280×800
LP121X04-A2 LG Display 12.1 1024×768
LP121X04-C2 LG Display 12.1 1024×768
LP121X05-A2 LG Display 12.1 1024×768
LP121X1-A2M1 LG Display 12.1 1024×768
