| Nomor Bagian | LP116WH7-SPC2 |
| Merek | LG Display |
| Ukuran | 11.6 |
| Aplikasi | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | eDP |
| merek panel | LG Display |
| model panel | LP116WH7-SPC2 (LGD04DC) |
| ukuran panel | 11.6" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 135PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 256.125(W)×144(H) mm |
| bukaan bezel | 259.25(W)×147.8(H) mm |
| ukuran garis besar | 268.35(W)×157.35(H) ×4.8(D) mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 220 cd/m² (Typ.) |
| rasio kontras | 600:1 (Typ.) (TM) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10) |
| mode tampilan | IPS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| menampilkan warna | 262K 49% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| gaya bentuk | Slim (PCBA Bent, T≤3.0mm) |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (2 Lanes) , HBR1 (2.7G/lane) , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
