| Nomor Bagian | LM290WW2-SSB1 |
| Merek | LG Display |
| Ukuran | 29.0 |
| Aplikasi | Desktop Monitor Indu |
| Resolusi | 2560×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 17S4P |
| Antarmuka | LVDS |
| merek panel | LG Display |
| ukuran panel | 29.0" |
| resolusi | 2560(RGB)×1080, CSHD, 96PPI |
| area tampilan | 672.768(W)×283.824(H) mm |
| ukuran garis besar | 693.6(W)×308.9(H) ×17.5(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 99% sRGB |
| frekuensi | 60Hz |
| berat panel | 3.12/3.28Kgs (Typ./Max.) |
| antarmuka sinyal | LVDS (4 ch, 8-bit) , 92 pins Connector |
| tegangan masukan | 10.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | LM290WW2-SSB1 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 14 (Typ.)(G to G) |
| jenis lampu | 17S4P WLED , 30K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Desktop Monitor Industrial Medical Imaging |
