| Nomor Bagian | LM230WF9-SSA1 |
| Merek | LG Display |
| Ukuran | 23.0 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek | LG Display |
| model | LM230WF9-SSA1 |
| ukuran diagonal | 23.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1080 [FHD] 95PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 509.184(H)×286.416(V) mm |
| garis besar redup. | 516.984(H)×302.708(V) ×14.2(D) mm |
| daerah bezel | - |
| perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
| pencahayaan | 250 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 14 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 72% NTSC |
| sumber cahaya | WLED [14S4P] , 30K hours , W/O Driver |
| berat | 1.79/1.88Kgs (Typ./Max.) |
| dirancang untuk | Desktop Monitor |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
