| Nomor Bagian | LM230WF9-S1A1 |
| Merek | LG Display |
| Ukuran | 23.0 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | |
| merek panel | LG Display |
| ukuran panel | 23.0" |
| resolusi | 1920(RGB)×1080, FHD, 95PPI |
| area tampilan | 509.184(W)×286.416(H) mm |
| kecerahan | - |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 72% NTSC |
| frekuensi | 60Hz |
| berat | - |
| model panel | LM230WF9-S1A1 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 14 (Typ.)(G to G) |
| jenis lampu | WLED , Without Driver |
| layar sentuh | Without |
| aplikasi | Desktop Monitor |
