| Nomor Bagian | LM230WF3-SLQ4 |
| Merek | LG Display |
| Ukuran | 23.0 |
| Aplikasi | Desktop Monitor |
| Resolusi | 1920×1080 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 18S2P |
| Antarmuka | LVDS |
| pabrikan | LG Display |
| nama model | LM230WF3-SLQ4 |
| ukuran layar | 23.0 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×1080 (FHD) 95PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 509.184 × 286.416 (H×V) |
| garis besar (mm) | 533.2 × 312 × 11 (H×V×D) |
| area bezel (mm) | 513.8 × 291.0 (H×V) |
| perlakuan | - |
| pencahayaan | - |
| rasio kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tanggapan | 14 (Typ.)(G to G) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | 18S2P WLED , 30K hours |
| massa | 1.93/2.03Kgs (Typ./Max.) |
| digunakan untuk | Desktop Monitor |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| jenis sinyal | LVDS (2 ch, 8-bit) , Connector 30 pins |
| sumber tegangan | 5.0V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM230WF1-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM230WF2-SLA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLB2 | LG Display | 23.0 | 1920×1080 |
| LM230WF3-SLD1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLD2 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TLG1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TRA1 | LG Display | 23.0 | 1920×1080 |
| LM230WF5-TRA2 | LG Display | 23.0 | 1920×1080 |
| LM230WFA-SLZ1 | LG Display | 23.0 | 1920×1080 |
| LM230WU3-STC3 | LG Display | 23.0 | 1920×1200 |
