Nomor Bagian | LM215WFA-SSA1 |
Merek | LG Display |
Ukuran | 21.5 |
Aplikasi | Desktop Monitor |
Resolusi | 1920×1080 |
Komposisi | LCM , a-Si TFT-LCD |
Kecerahan | |
CR | 1000:1 |
Warna | 16.7M |
Lampu latar | WLED |
Antarmuka | LVDS |
pabrikan | LG Display |
ukuran layar | 21.5 inch |
nomor piksel | 1920(RGB)×1080 (FHD) 102PPI |
area aktif (mm) | 476.064 × 267.786 (H×V) |
area bezel (mm) | - |
pencahayaan | 250 cd/m² (Typ.) |
sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
pemandangan bagus di | Symmetry |
kedalaman warna | 16.7M 72% NTSC |
massa | 1.59/1.67Kgs (Typ./Max.) |
tingkat penyegaran | 60Hz |
jenis sinyal | LVDS (2 ch, 8-bit) , 30 pins Connector |
sumber tegangan | 5.0V (Typ.) |
maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
nama model | LM215WFA-SSA1 |
tipe layar | LCM , a-Si TFT-LCD |
pengaturan | RGB Vertical Stripe |
garis besar (mm) | 484.5 × 284.4 × 12.7 (H×V×D) |
perlakuan | Antiglare (Haze 25%), Hard coating (3H) |
rasio kontras | 1000 : 1 (Typ.) (TM) |
tanggapan | 14 (Typ.)(G to G) ms |
mode kerja | IPS, Normally Black, Transmissive |
lampu latar | WLED , 30K hours , No Driver |
digunakan untuk | Desktop Monitor |
layar sentuh | In-Cell Touch |
