| Nomor Bagian | LM171WX3-TLB2 |
| Merek | LG Display |
| Ukuran | 17.1 |
| Aplikasi | DMPC |
| Resolusi | 1440×900 |
| Komposisi | LCM |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | LG.Philips LCD |
| model panel | LM171WX3-TLB2 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 17.1 inch |
| resolusi | 1440(RGB)×900 , WXGA+ |
| mode tampilan | Transmissive |
| daerah aktif | 367.2×229.5 mm |
| permukaan | |
| kecerahan | |
| rasio kontras | |
| menampilkan warna | 16.7M (6-bit + Hi-FRC), CIE193160% |
| waktu merespon | |
| sudut pandang | |
| frekuensi | 60Hz |
| jenis lampu | 2 pcsCCFL |
| antarmuka sinyal | LVDS (2 ch, 8-bit) |
| roh: | |
| aplikasi | DMPC |
