| Nomor Bagian | LH520WF1-SD01 |
| Merek | LG Display |
| Ukuran | 5.2 |
| Aplikasi | MPH |
| Resolusi | 1080×1920 |
| Komposisi | Assembly |
| Kecerahan | 380 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | LG Display |
| model panel | LH520WF1-SD01 |
| tipe panel | LTPS TFT-LCD , Assembly |
| ukuran panel | 5.2 inch |
| resolusi | 1080(RGB)×1920 , FHD |
| daerah aktif | 64.8×115.2 mm |
| garis besar | 69.4×136.4×2.47 mm |
| permukaan | Clear |
| kecerahan | 380 cd/m² (Typ.) |
| rasio kontras | 700:1 (Typ.) |
| menampilkan warna | 16.7M (8-bit), CIE193170% |
| sudut pandang | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| antarmuka sinyal | MIPI (4 data lanes), 30 pins |
| tegangan masukan | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| aplikasi | MPH |
