| Nomor Bagian | LD860DBN-UJA2 |
| Merek | LG Display |
| Ukuran | 86 |
| Aplikasi | Digital Signage Outd |
| Resolusi | 3840×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1100:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antarmuka | V-by-One |
| merek | LG Display |
| model | LD860DBN-UJA2 |
| ukuran diagonal | 86 inch (Native bar) |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 3840(RGB)×600 45PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 2148.48(H)×335.7(V) mm |
| garis besar redup. | 2158.3(H)×348.5(V) ×82.2(D) mm |
| daerah bezel | 2149.5(H)×336.7(V) mm |
| perlakuan | Antiglare (Haze 10%), Hard coating (3H) |
| pencahayaan | 700 cd/m² (Typ.) |
| rasio kontras | 1100:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 8 (Typ.)(G to G) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 1.07B 98% sRGB |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat | 15.04Kgs (Typ.) |
| dirancang untuk | Digital Signage Outdoor High Brightness Stretched Bar LCD |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | V-by-One 8 lane , 51 pins Connector |
| Sumber Daya listrik | 12.0V (Typ.) |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
