| Nomor Bagian | LD089WU1-SM01 |
| Merek | LG Display |
| Ukuran | 8.9 |
| Aplikasi | PAD |
| Resolusi | 1920×1200 |
| Komposisi | LCM |
| Kecerahan | 360 |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antarmuka | MIPI |
| merek panel | LG Display |
| model panel | LD089WU1-SM01 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 8.9 inch |
| resolusi | 1920(RGB)×1200 , WUXGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 191.52×119.7 mm |
| garis besar | 203.4×135.85×5.25 mm |
| permukaan | Hard coating |
| kecerahan | 360 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 35 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 7S5PWLEDWithout Driver |
| antarmuka sinyal | MIPI (4 data lanes), 45 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | PAD |
| B089AW01 V1 | AUO | 8.9 | 1024×600 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| HSD089IFW1-B00 | HannStar | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP089WS1-TLA1 | LG Display | 8.9 | 1024×600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| A090PAN01.0 | AUO | 9.0 | 900×1440 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| HV089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LD083WU1-SPA3 | LG Display | 8.3 | 1200×1920 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
| N080ICE-GB0 Rev.B1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
