| Nomor Bagian | LD070WS2-SL05 |
| Merek | LG Display |
| Ukuran | 7.0 |
| Aplikasi | UMPC |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek panel | LG Display |
| model panel | LD070WS2-SL05 2 Compatible model |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 7.0 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mode tampilan | IPS, Normally Black, Transmissive |
| daerah aktif | 153.6×90 mm |
| garis besar | 162.8×102.9×4.17 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| waktu merespon | 50 (Max.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 5S4PWLEDWithout Driver |
| antarmuka sinyal | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | UMPC |
