| Nomor Bagian | LC650EQ3-SMA1 |
| Merek | LG Display |
| Ukuran | 65 |
| Aplikasi | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 1400:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | EPI |
| merek panel | LG Display |
| ukuran panel | 65" |
| resolusi | 3840(RGB)×2160, UHD, 68PPI |
| area tampilan | 1428.48(W)×803.52(H) mm |
| ukuran garis besar | 1440.3(W)×818.3(H) ×1.2(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| kedalaman kaca | - |
| menampilkan warna | 1.07B 83% NTSC |
| frekuensi | 120Hz |
| ic pengemudi | COF Built-in 12 source chips |
| berat panel | 3.60/3.78Kgs (Typ./Max.) |
| antarmuka sinyal | EPI , 136 pins Connector |
| tegangan masukan | 12.0V (Typ.)(VLCD) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | LC650EQ3-SMA1 |
| tipe panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 3%), Hard coating (2H) |
| rasio kontras | 1400:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 8/10 (Typ.)(Tr/Td) |
| keterusan | 4.38% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| layar sentuh | Without |
| aplikasi | TV Sets |
