LC550EUD-SCA1

LC550EUD-SCA1
LC550EUD-SCA1
LC550EUD-SCA1 thumb LC550EUD-SCA1 thumb
Merek
LG Display
Ukuran
55
Aplikasi
LCTV
Resolusi
1920×1080
Komposisi
LCM
Kecerahan
450
CR
1400:1
Warna
16.7M/1.06B
Lampu latar
WLED
Antarmuka
LVDS
In Stock
14596
Spesifikasi

Nomor Bagian LC550EUD-SCA1
MerekLG Display
Ukuran55
AplikasiLCTV
Resolusi1920×1080
KomposisiLCM
Kecerahan450
CR1400:1
Warna16.7M/1.06B
Lampu latarWLED
AntarmukaLVDS
merek panelLG Display
model panelLC550EUD-SCA1
tipe panel a-Si TFT-LCD , LCM
ukuran panel55 inch
resolusi1920(RGB)×1080 , FHD
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif1209.6×680.4 mm
garis besar1261.6×732.4 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kecerahan450 cd/m² (Typ.)
rasio kontras1400:1 (Typ.)
menampilkan warna16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
waktu merespon5 (Typ.)(G to G); 8 (Typ.)(MPRT)
sudut pandang89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frekuensi120Hz+120Hz
jenis lampuWLEDEmbedded (LED Driver)
antarmuka sinyalLVDS (4 ch, 8/10-bit), 100 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
