| Nomor Bagian | LC470EUG-PEF2 |
| Merek | LG Display |
| Ukuran | 47 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1400:1 |
| Warna | 1.06B |
| Lampu latar | WLED |
| Antarmuka | EPI |
| merek panel | LG Display |
| model panel | LC470EUG-PEF2 |
| ukuran panel | 47" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 46PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 1039.68(W)×584.82(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 1059.5(W)×616.2(H) mm |
| permukaan | Antiglare (Haze 1%), Hard coating (2H) |
| kecerahan | 360 cd/m² (Typ.) |
| rasio kontras | 1400:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| mode tampilan | S-IPS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 8/10 (Typ.)(Tr/Td) |
| menampilkan warna | 1.06B 68% NTSC |
| jenis lampu | WLED , 50K hours , Without Driver |
| frekuensi | 120Hz |
| layar sentuh | Without |
| berat panel | 10.5/11.0Kgs (Typ./Max.) |
| aplikasi | TV Sets |
| antarmuka sinyal | EPI , 100 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
