LC260WX2-SLB2


Merek
LG Display
Ukuran
26.0
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
LCM
Kecerahan
500
CR
700:1
Warna
16.7M
Lampu latar
EEFL
Antarmuka
LVDS
In Stock
14686
Spesifikasi

Nomor Bagian LC260WX2-SLB2
MerekLG Display
Ukuran26.0
AplikasiLCTV
Resolusi1366×768
KomposisiLCM
Kecerahan500
CR700:1
Warna16.7M
Lampu latarEEFL
AntarmukaLVDS
merek panelLG.Philips LCD
model panelLC260WX2-SLB2
tipe panel a-Si TFT-LCD , LCM
ukuran panel26.0 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanS-IPS, Normally Black, Transmissive
daerah aktif575.769×323.712 mm
garis besar626×373 mm
permukaanAntiglare, Hard coating (3H)
kecerahan500 cd/m² (Typ.)
rasio kontras700:1 (Typ.)
menampilkan warna16.7M (8-bit)
waktu merespon9/9 (Typ.)(Tr/Td); 8 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
jenis lampu17 pcsEEFLEmbedded (Inverter)
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
