| Nomor Bagian | LC156LF1L03 |
| Merek | PANDA |
| Ukuran | 15.6 |
| Aplikasi | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD, CELL |
| Kecerahan | |
| CR | - |
| Warna | 262K |
| Lampu latar | No |
| Antarmuka | eDP |
| merek panel | PANDA |
| model panel | LC156LF1L03 |
| ukuran panel | 15.6" |
| tipe panel | Oxide TFT-LCD, CELL |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 344.16(W)×193.59(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 354.36(W)×204.04(H) ×1.076(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 0 cd/m² |
| rasio kontras | - |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | FFS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 25 (Typ.)(Tr+Td) |
| kedalaman kaca | 0.40+0.40 mm |
| keterusan | 6.5% (Typ.) |
| menampilkan warna | 262K 47% NTSC |
| jenis lampu | No B/L , With LED Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| ic pengemudi | COGBuilt-in 4 source + 2 gate chips |
| gaya bentuk | - |
| aplikasi | Laptop |
| antarmuka sinyal | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
