| Nomor Bagian | LA123WF4-SR03 |
| Merek | LG Display |
| Ukuran | 12.3 |
| Aplikasi | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | RSDS |
| merek | LG Display |
| model | LA123WF4-SR03 |
| ukuran diagonal | 12.3 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×720 167PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 292.032(H)×109.512(V) mm |
| garis besar redup. | 310(H)×128(V) ×10.75(D) mm |
| daerah bezel | 296.03(H)×113.5(V) mm |
| perlakuan | Hard coating |
| pencahayaan | 600 cd/m² (Min.) |
| rasio kontras | 800:1 (Min.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 77% NTSC |
| sumber cahaya | WLED [11S4P] , 10K hours , W/O Driver |
| berat | 385/400g (Typ./Max.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | RSDS (2 Channel) , 110 pins FPC |
| Sumber Daya listrik | 3.3/13.0V (Typ.)(VCC/VDD) |
| lingkungan | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
