| Nomor Bagian | LA123WF4-SL02 |
| Merek | LG Display |
| Ukuran | 12.3 |
| Aplikasi | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.7M |
| Lampu latar | 11S4P |
| Antarmuka | |
| pabrikan | LG Display |
| nama model | LA123WF4-SL02 |
| ukuran layar | 12.3 inch |
| tipe layar | LCM, a-Si TFT-LCD |
| nomor piksel | 1920(RGB)×720 167PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 292.032 × 109.512 (H×V) |
| garis besar (mm) | 310.4 × 128.9 (H×V×D) |
| area bezel (mm) | - |
| perlakuan | Hard coating |
| pencahayaan | 650 cd/m² (Typ.) |
| rasio kontras | 900 : 1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Min.)(CR≥10) |
| tanggapan | 30 (Typ.)(Tr+Td) ms |
| pemandangan bagus di | Symmetry |
| mode kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 86% NTSC |
| lampu latar | 11S4P WLED , 10K hours , No Driver |
| massa | 481/496g (Typ./Max.) |
| digunakan untuk | Automotive Display |
| tingkat penyegaran | 60Hz |
| layar sentuh | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
