| Nomor Bagian | LA090WH1-SL01 |
| Merek | LG Display |
| Ukuran | 9.0 |
| Aplikasi | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | LG Display |
| model | LA090WH1-SL01 |
| ukuran diagonal | 9.0 inch |
| jenis | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×720 [WXGA] 164PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 200.448(H)×106.056(V) mm |
| garis besar redup. | 213.2(H)×121.2(V) ×8.6(D) mm |
| daerah bezel | 203.148(H)×108.756(V) mm |
| perlakuan | Antiglare |
| pencahayaan | 600 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) (TM) |
| arah pandangan | Symmetry |
| waktu merespon | 17/13 (Max.)(Tr/Td) |
| sudut pandang | 80/80/80/80 (Min.)(CR≥10) |
| Modus operasi | IPS, Normally Black, Transmissive |
| warna pendukung | 16.7M 65% NTSC |
| sumber cahaya | WLED [6S3P] , 10K hours , W/O Driver |
| berat | 219/224g (Typ./Max.) |
| dirancang untuk | Automotive Display |
| kecepatan bingkai | 60Hz |
| panel sentuh | Without |
| tipe antarmuka | LVDS (1 ch, 8-bit) , 60 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
