| Nomor Bagian | LA070WV6-SD02 |
| Merek | LG Display |
| Ukuran | 7.0 |
| Aplikasi | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 5S2P |
| Antarmuka | Parallel |
| merek panel | LG Display |
| ukuran panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| area tampilan | 152.4(W)×91.44(H) mm |
| ukuran garis besar | 166.6(W)×105.8(H) ×10.5(D) mm |
| kecerahan | 610 cd/m² (Typ.) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| menampilkan warna | 16.7M 60% NTSC |
| frekuensi | 60Hz |
| berat panel | 180/185g (Typ./Max.) |
| antarmuka sinyal | Parallel RGB (1 ch, 6-bit) , 66 pins FPC |
| tegangan masukan | 3.3/13.0/18.5/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| model panel | LA070WV6-SD02 |
| tipe panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | 155.0(W)×94.0(H) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| mode tampilan | IPS, Normally Black, Transmissive |
| waktu merespon | 15/10 (Typ.)(Tr/Td) |
| jenis lampu | 5S2P WLED , 20K hours , Without Driver |
| layar sentuh | Without |
| aplikasi | Automotive Display |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LA070WV1-TH01 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD03 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SL02 | LG Display | 7.0 | 800×480 |
