| Nomor Bagian | KHS072VG1MB-G40 |
| Merek | Kyocera |
| Ukuran | 7.2 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | CSTN-LCD, LCM |
| Kecerahan | |
| CR | 5:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antarmuka | |
| merek | Kyocera |
| model | KHS072VG1MB-G40 |
| ukuran diagonal | 7.2 inch |
| jenis | CSTN-LCD, LCM |
| format piksel | 640(RGB)×480 [VGA] 111PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 145.9(H)×109.42(V) mm |
| garis besar redup. | 179.3(H)×130.5(V) ×6.5(D) mm |
| daerah bezel | 147.9(H)×111.42(V) mm |
| perlakuan | - |
| pencahayaan | - |
| rasio kontras | 5:1 (Typ.) (RF) |
| arah pandangan | - |
| waktu merespon | 200/150 (Typ.)(Tr/Td) |
| sudut pandang | 50/50/40/30 (Typ.)(CR≥2) |
| Modus operasi | STN, Normally Black, Transflective |
| warna pendukung | Color |
| sumber cahaya | CCFL [1 pcs] , 40K hours , Optional |
| berat | - |
| dirancang untuk | Industrial |
| kecepatan bingkai | 75Hz |
| panel sentuh | Without |
| lingkungan | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
