| Nomor Bagian | KHS038AA1AG-G83 |
| Merek | Kyocera |
| Ukuran | 3.8 |
| Aplikasi | Industrial |
| Resolusi | 240×320 |
| Komposisi | LCM , CSTN-LCD |
| Kecerahan | |
| CR | 15:1 |
| Warna | Color |
| Lampu latar | 1 |
| Antarmuka | Parallel |
| pabrikan | Kyocera |
| ukuran layar | 3.8 inch |
| nomor piksel | 240(RGB)×320 (QVGA) 105PPI |
| area aktif (mm) | 57.58 × 76.78 (H×V) |
| pencahayaan | 16 cd/m² (Typ.) |
| sudut pandang | 50/45/20/30 (Typ.)(CR≥2) |
| pemandangan bagus di | - |
| kedalaman warna | Color |
| massa | - |
| tingkat penyegaran | 75Hz |
| jenis sinyal | Parallel Data (1ch, 8-bit) FPC |
| sumber tegangan | 3.3V (Typ.) |
| maks. peringkat | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | KHS038AA1AG-G83 |
| tipe layar | LCM , CSTN-LCD |
| pengaturan | RGB Vertical Stripe |
| garis besar (mm) | - |
| rasio kontras | 15 : 1 (Typ.) (TM) |
| tanggapan | 250/150 (Typ.)(Tr/Td) ms |
| mode kerja | STN, Normally Black, Transflective |
| lampu latar | 1 pcs CCFL , No Driver |
| digunakan untuk | Industrial |
| layar sentuh | - |
