| Nomor Bagian | KCS6448ESTT-X1 |
| Merek | Kyocera |
| Ukuran | 7.7 |
| Aplikasi | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM, CSTN-LCD |
| Kecerahan | |
| CR | 20:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antarmuka | |
| pabrikan | Kyocera |
| nama model | KCS6448ESTT-X1 |
| ukuran layar | 7.7 inch |
| tipe layar | LCM, CSTN-LCD |
| nomor piksel | 640(RGB)×480 (VGA) 103PPI |
| pengaturan | RGB Vertical Stripe |
| area aktif (mm) | 157.42 × 118.06 (H×V) |
| garis besar (mm) | 199 × 147 × 10.5 (H×V×D) |
| area bezel (mm) | 160.42 × 121.06 (H×V) |
| perlakuan | Antiglare |
| pencahayaan | - |
| rasio kontras | 20 : 1 (Typ.) (TM) |
| sudut pandang | 50/50/40/30 (Typ.)(CR≥2) |
| tanggapan | 160/80 (Typ.)(Tr/Td) ms |
| pemandangan bagus di | - |
| mode kerja | STN, Normally Black, Transmissive |
| kedalaman warna | Color |
| lampu latar | CCFL |
| massa | - |
| digunakan untuk | Industrial |
| tingkat penyegaran | 75Hz |
| layar sentuh | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
