| Nomor Bagian | KCG057QV1DL-G770 |
| Merek | Kyocera |
| Ukuran | 5.7 |
| Aplikasi | Industrial |
| Resolusi | 320×240 |
| Komposisi | CSTN-LCD, LCM |
| Kecerahan | |
| CR | 55:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antarmuka | Parallel |
| merek | Kyocera |
| model | KCG057QV1DL-G770 |
| ukuran diagonal | 5.7 inch |
| jenis | CSTN-LCD, LCM |
| format piksel | 320(RGB)×240 [QVGA] 70PPI |
| konfigurasi | RGB Vertical Stripe |
| daerah aktif | 115.2(H)×86.4(V) mm |
| garis besar redup. | 144(H)×104.8(V) ×15.3(D) mm |
| daerah bezel | 119.4(H)×90.6(V) mm |
| perlakuan | Hard coating (2H) |
| pencahayaan | - |
| rasio kontras | 55:1 (Typ.) (TM) |
| arah pandangan | - |
| waktu merespon | 180/170 (Typ.)(Tr/Td) |
| sudut pandang | 50/50/20/35 (Typ.)(CR≥2) |
| Modus operasi | STN, Normally Black, Transmissive |
| warna pendukung | Color |
| sumber cahaya | CCFL [1 pcs] |
| berat | 220g (Typ.) |
| dirancang untuk | Industrial |
| kecepatan bingkai | 75Hz |
| panel sentuh | 4-wire Resistive Touch |
| tipe antarmuka | Parallel Data (1ch, 8-bit) Connector |
| Sumber Daya listrik | 3.3/5.0V (Typ.)(VDD) |
| lingkungan | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
