| Nomor Bagian | HVA37WV1-ME0 |
| Merek | HYDIS |
| Ukuran | 3.7 |
| Aplikasi | MPH |
| Resolusi | 480×800 |
| Komposisi | LCM |
| Kecerahan | 400 |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antarmuka | TTL |
| merek panel | HYDIS |
| model panel | HVA37WV1-ME0 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 3.7 inch |
| resolusi | 480(RGB)×800 , WVGA |
| mode tampilan | HFFS, Normally Black, Transmissive |
| daerah aktif | 48.24×80.4 mm |
| garis besar | 52.54×89.5×1.9 mm |
| permukaan | |
| kecerahan | 400 cd/m² (Typ.) |
| rasio kontras | 800:1 (Typ.) |
| menampilkan warna | 16.2M (6-bit + Dithering), CIE193171% |
| waktu merespon | 33 (Typ.)(Tr+Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 8S1PWLEDWithout Driver |
| antarmuka sinyal | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| tegangan masukan | 1.8/3.0V (Typ.)(IOVCC/VCC) |
| aplikasi | MPH |
| C0283QGLD-T | CMEL | 2.8 | 240×320 |
| CLAF055WB41 TXX | CPT | 5.5 | 720×1280 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| LH350H02-FD02 | LG Display | 3.5 | 320×480 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LS038Y3LX01 | SHARP | 3.8 | 480×800 |
| LS055T3SX05 | SHARP | 5.5 | 1080×1920 |
| TM020HDZ05 | Tianma | 2.0 | 240×320 |
| TM045YDH27 | Tianma | 4.5 | 480×854 |
| TM055XDHP10 | Tianma | 5.5 | 540×960 |
