| Nomor Bagian | HV490FHB-N8L |
| Merek | BOE |
| Ukuran | 49 |
| Aplikasi | TV Sets |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antarmuka | |
| merek panel | BOE |
| ukuran panel | 49" |
| resolusi | 1920(RGB)×1080, FHD, 45PPI |
| area tampilan | 1073.78(W)×604(H) mm |
| ukuran garis besar | 1084.8(W)×616.3(H) ×1.32(D) mm |
| kecerahan | 0 cd/m² |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| tampilan terbaik di | Symmetry |
| kedalaman kaca | 0.50+0.50 mm |
| menampilkan warna | 16.7M 73% NTSC |
| frekuensi | 60Hz |
| berat | 1.93Kgs (Typ.) |
| model panel | HV490FHB-N8L |
| tipe panel | a-Si TFT-LCD , CELL |
| format piksel | RGB Vertical Stripe |
| bukaan bezel | - |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| rasio kontras | 1200:1 (Typ.) (TM) |
| mode tampilan | ADS, Normally Black, Transmissive |
| waktu merespon | 8 (Typ.)(G to G) |
| keterusan | 6.0% (Typ.)(with Polarizer) |
| jenis lampu | No B/L |
| layar sentuh | Without |
| aplikasi | TV Sets |
| HV490FHB-N80 | BOE | 49 | 1920×1080 |
| LC490DUJ-SGE3 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA1 | LG Display | 49 | 1920×1080 |
| LC490DUY-SHA2 | LG Display | 49 | 1920×1080 |
| LC490EGE-FHM1 | LG Display | 49 | 3840×2160 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| LC490EUE-FHM1 | LG Display | 49 | 1920×1080 |
| MT4851D01-1 | CSOT | 49 | 3840×2160 |
| ST4851D01-2 | CSOT | 49 | 3840×2160 |
