| Nomor Bagian | HV430QUB-H10 |
| Merek | BOE |
| Ukuran | 43 |
| Aplikasi | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antarmuka | V-by-One |
| merek panel | BOE |
| model panel | HV430QUB-H10 |
| ukuran panel | 43" |
| tipe panel | a-Si TFT-LCD, CELL |
| resolusi | 3840(RGB)×2160, UHD, 103PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 941.184(W)×529.416(H) mm |
| bukaan bezel | - |
| ukuran garis besar | 953(W)×543(H) ×1.34(D) mm |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| rasio kontras | 1200:1 (Typ.) (TM) |
| sudut pandang | 89/89/89/89 (Typ.)(CR≥10) |
| mode tampilan | ADS, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| keterusan | 4.1% (Typ.)(with Polarizer) |
| menampilkan warna | 1.07B 72% NTSC |
| jenis lampu | No B/L |
| frekuensi | 120Hz (60Hz Input) |
| layar sentuh | Without |
| ic pengemudi | COF Built-in 6 source chips |
| berat panel | 1.58Kgs (Typ.) |
| aplikasi | TV Sets |
| antarmuka sinyal | V-by-One 8 lane , 51 pins Connector |
| tegangan masukan | 12.0V (Typ.) |
| lingkungan | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
