HV320WX2-200

HV320WX2-200
HV320WX2-200
HV320WX2-200 thumb HV320WX2-200 thumb
Merek
BOE
Ukuran
31.5
Aplikasi
LCTV
Resolusi
1366×768
Komposisi
CELL
Kecerahan
0
CR
1200:1
Warna
16.7M
Lampu latar
No B/L
Antarmuka
LVDS
In Stock
10234
Spesifikasi

Nomor Bagian HV320WX2-200
MerekBOE
Ukuran31.5
AplikasiLCTV
Resolusi1366×768
KomposisiCELL
Kecerahan0
CR1200:1
Warna16.7M
Lampu latarNo B/L
AntarmukaLVDS
merek panelBOE
model panelHV320WX2-200
tipe panel a-Si TFT-LCD , CELL
ukuran panel31.5 inch
resolusi1366(RGB)×768 , WXGA
mode tampilanAFFS, Normally Black, Transmissive
daerah aktif697.685×392.256 mm
garis besar716×411.1 mm
permukaanAntiglare (Haze 10%), Hard coating (3H)
kedalaman kaca0.70+0.70 mm
keterusan5.25% (Typ.)(with Polarizer)
rasio kontras1200:1 (Typ.)
menampilkan warna16.7M (8-bit)
waktu merespon8 (Typ.)(G to G)
sudut pandang89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frekuensi60Hz
antarmuka sinyalLVDS (1 ch, 8-bit), 30 pins
tegangan masukan12.0V (Typ.)
aplikasiLCTV
Model Keluarga
HV320WHB-N00 BOE 31.5 1366×768
HV320WHB-N06 BOE 31.5 1366×768
HV320WHB-N80 BOE 31.5 1366×768
HV320WX2-200 BOE 31.5 1366×768
HV320WX2-201 BOE 31.5 1366×768
HV320WX2-206 BOE 31.5 1366×768
HV320WX2-500 BOE 31.5 1366×768
HV320WXC-100 BOE 31.5 1366×768
HV320WXC-201 BOE 31.5 1366×768
