| Nomor Bagian | HV150UX1-100 |
| Merek | HYDIS |
| Ukuran | 15.0 |
| Aplikasi | NBPC |
| Resolusi | 1600×1200 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antarmuka | LVDS |
| merek panel | BOE HYDIS |
| model panel | HV150UX1-100 |
| tipe panel | a-Si TFT-LCD , LCM |
| ukuran panel | 15.0 inch |
| resolusi | 1600(RGB)×1200 , UXGA |
| mode tampilan | FFS, Normally Black, Transmissive |
| daerah aktif | 304.8×228.6 mm |
| garis besar | 317.3×242×6.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Antiglare (Haze 45%), Hard coating (2H), Antireflection |
| kecerahan | 200 cd/m² (Typ.) |
| rasio kontras | 500:1 (Typ.) |
| menampilkan warna | 262K (6-bit) |
| waktu merespon | 30/30 (Typ.)(Tr/Td) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frekuensi | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antarmuka sinyal | LVDS (2 ch, 6-bit), 30 pins |
| tegangan masukan | 3.3V (Typ.) |
| aplikasi | NBPC |
