| Nomor Bagian | HSD150GXN1-A00-C00 |
| Merek | HannStar |
| Ukuran | 15.0 |
| Aplikasi | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antarmuka | LVDS |
| merek | HannStar |
| ukuran diagonal | 15.0 inch |
| format piksel | 1024(RGB)×768 [XGA] 85PPI |
| daerah aktif | 304.128(H)×228.096(V) mm |
| daerah bezel | 307.4(H)×231.3(V) mm |
| pencahayaan | 250 cd/m² (Typ.) |
| arah pandangan | - |
| sudut pandang | 80/80/60/80 (Typ.)(CR≥10) |
| warna pendukung | 262K/16.2M 60% NTSC |
| berat | 1.20Kgs (Max.) |
| kecepatan bingkai | 60Hz |
| tipe antarmuka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Sumber Daya listrik | 3.3V (Typ.) |
| lingkungan | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| model | HSD150GXN1-A00-C00 |
| jenis | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar redup. | 326.5(H)×253.5(V) ×12.7(D) mm |
| perlakuan | - |
| rasio kontras | 700:1 (Typ.) (TM) |
| waktu merespon | 12 (Typ.)(Tr+Td) |
| Modus operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| dirancang untuk | Industrial |
| panel sentuh | Embeded Touch |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
| HSD150PX16-A | HannStar | 15.0 | 1024×768 |
| LC150X01-A3K2 | LG Display | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
