| Nomor Bagian | HSD123JPW1-A20 |
| Merek | HannStar |
| Ukuran | 12.3 |
| Aplikasi | Outdoor High Brightn |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 11S4P |
| Antarmuka | LVDS |
| merek panel | HannStar |
| model panel | HSD123JPW1-A20 |
| ukuran panel | 12.3" |
| tipe panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×720, 167PPI |
| format piksel | RGB Vertical Stripe |
| area tampilan | 292.032(W)×109.512(H) mm |
| bukaan bezel | 294.8(W)×112.1(H) mm |
| ukuran garis besar | 308.1(W)×130(H) ×16.6(D) mm |
| permukaan | Antiglare |
| kecerahan | 850 cd/m² (Typ.) |
| rasio kontras | 1000:1 (Typ.) (TM) |
| sudut pandang | 85/85/85/85 (Typ.)(CR≥10) |
| mode tampilan | IPS Pro, Normally Black, Transmissive |
| tampilan terbaik di | Symmetry |
| waktu merespon | 18/17 (Typ.)(Tr/Td) |
| menampilkan warna | 16.7M 70% NTSC |
| jenis lampu | 11S4P WLED , 30K hours , Without Driver |
| frekuensi | 60Hz |
| layar sentuh | Without |
| berat panel | 520g (Typ.) |
| aplikasi | Outdoor High Brightness Automotive Display |
| antarmuka sinyal | LVDS (2 ch, 8-bit) , 50 pins Connector |
| tegangan masukan | 3.3V (Typ.) |
| lingkungan | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
